- CPU Socket:Supports Intel LGA2011-3 platform processors
- CPU Type: LGA 2011-3,X99-T8D / T8 / AD3 / BD3 / 8MD3 / 8M-T / QD3, "T" stands for "THREE", which means the motherboard USES DDR3 memory and only supports E5 2629V3/2649V3/2669V3/2696V3/2673V3/2676V3/2678V3/2696V4,other type does not support or untested
- Main máy chủ chipset: Q87 ... Etc chipset shipped randomly
- Memory Socket:4*DDR3 memory socket,Maximum Memory Capacity 128G
- Memory Standard:Support Four channel DDR3 1866/1600/1333MHz
- SATA Inderface:6 *SATA3.0 6Gb/s interface
- Extended Inderface:2*M.2 2280 NVME PCIE X4 3.0 32Gb/s;4*USB2.0;2*USB3.0;1*network interface; 1*3-hole audio interface
- Expansion Slots:1*PCI Express 3.0 x16;1*PCI Express 3.0 x4;1*PCI Express 2.0 x1
- Soud Track:Realtek High Definition Audio
- Network interface:Gigabit Ethernet
- Power interface:24pin+8pin
- Fan interface:2 *CPU_FAN + 1* SYS_FAN
- PCB layer:6 layer PCB,6Phases power supply
- Dimension:245*190MM M-ATX
